Quickly heat the aluminum shells of the motor and the pump housing, etc.
Internal encapsulation with epoxy resin, sturdy and durable with a rotating beam.
Easy to operate and heats up quickly.
|
Model number
|
BHDJ-240
|
BHDJ-280
|
BHDJ-330
|
BHDJ-380
|
|
Apparent Power KVA
|
10
|
12
|
14
|
20
|
|
Input Voltage V
|
380
|
380
|
380
|
380
|
|
Input CurrentA
|
30
|
30
|
40
|
40
|
|
Space between Two Columns (Width x Height) mm
|
240*150
|
280*200
|
340*200
|
380*230
|
|
Heating Rod Size mm
|
60*60*540
|
60*60*620
|
70*70*680
|
70*70*720
|
|
Overall Dimensions mm
|
700*400*980
|
700*400*1030
|
Mainframe: 640*400*790; Electrical cabinet: 400*420*620
|
Mainframe: 680*400*790; Electrical cabinet: 400*420*620
|
|
Minimum Inner Diameter of Heated Workpiece mm
|
90
|
90
|
100
|
100
|
|
Maximum Outer Diameter of Heated Workpiece mm
|
300
|
460
|
470
|
530
|
|
Maximum Length of Heated Workpiece mm
|
210
|
250
|
310
|
350
|
|
Control method
|
Manual/Automatic/Time
|
Manual/Automatic/Time
|
Manual/Automatic/Time
|
Manual/Automatic/Time
|
